Description
- 4.5m working height
- Low platform entry height only 360mm
- Only 1.19m x 0.75m working footprint
- Passes easily through single doorways
- Large 1.0m x 0.73m platform size, gives the user more room to work
- Heavy duty Auto-Lok wheels on elevation
- Handrail protection already in place from the ground up
- Fits through standard single doorways and into passenger lifts
- Up to 300 lifts per charge
OPERATING SPECIFICATIONS
Maximum working height: 4.50m
Maximum platform height: 2.50m
Closed platform height: 0.36m
Platform dimensions: 1.00m x 0.73m
Working footprint: 1.19m x 0.75m
Safe working load: 200kg (1 person plus tools)
CLOSED DIMENSIONS
Length: 1.195m
Width: 0.75m
Height: 1.56m
Weight: 285kg
Power: 12V D.C. Battery.
Controls: Simple push button heavy duty pendant controls for ground and platform.
Construction: Heavy duty fabricated steel superstructure and 2 stage mast with Ultra-Glide technology. Tough, powder coated finish.
Safety: Full fail-safe hydraulic circuit. Auto-Lok wheels.
Options: 110V or 230V mains power. Tilt alarm with auto cut-out. Protective storage cover
