Description
SAFETY FEATURES
- Auto-braked on entering basket
- ‘Auto-lok’ brake on elevation
- Dead Man’s handle
- Fail-safe lifting mechanism
OPERATING SPECIFICATIONS
Maximum working height: 4.20m
Maximum platform height: 2.20m
Basket dimensions: 850mm(L) x 644mm (W)
Working footprint: 1.28m x 950mm
Safe working load: 150kg (1 person + tools)
Maximum manual force: 200N
Maximum gradient for operation: 3º
Maximum wind force: Internal/External use. 12.5m/s
Maximum wheel force: 245kg (2.4kN)
Maximum castor point load: 245kg
Sound pressure level: Less than 70Dba
CLOSED DIMENSIONS
Length: 1.28m
Width: 0.95m
Height: 1.94m
Weight: 335kg
LIFT CYCLES Unlimited
